Product Description
SB series exposure machine is a new type of automatic plate printing machine used for printing PS plate, PVA plate and other printing plates. This series of printing plate exposure machine adopts microcomputer control, data display button setting, parameter storage, and easy operation. Convenient, the plate-making light source adopts iodine gallium lamp, and its spectral characteristics are consistent with the photosensitive characteristics of the plate. The plate making speed is fast and the quality is good.
Working Principle
The printing process of this exposure machine can be simply understood as an exposure process. The rubber sealing ring is in contact with the working glass to form a sealed membrane cavity for the original and printing plate. The vacuum pump draws out the air in the membrane cavity to form a vacuum in the cavity. The vacuum negative pressure makes the original and the printing plate close to the working glass plane, and the iodine gallium light source vertically exposes the photosensitive layer of the printing plate from top to bottom within a predetermined time, and the exposure is completed when the printing is completed.
Technical Data Sheet
Product number | Print area | Uniformity of illumination | vacuum | Power source voltage | Dimensions | Exposure method |
SB1000 | 1000*800 | 85% | 0.08Mpa | 2KW/220V | 1110*910*1940 | Shutter closed |
SB1100 | 1100*900 | 2KW/220V | 1210*1110*2000 | |||
SB1300 | 1300*1100 | 3KW/220V | 1430*1210*2520 |
Picture Display
It's the real picture, if you want more pictures and information please feel free to contact us. We can tell you more details about this machine and provide some technology supports.
Packaging & Shipping
In order to better ensure the safety of our goods, we will provide professional, environmentally friendly, convenient and efficient packaging services and transportation.
Company Profile
Shandong Topower Pte.,Ltd was created in 2017 as a famous manufacture in China who supplied high grade printing products service and solutions, which are focus on service to printing industry.Our main products are zinc plate, magnesium plate, copper plate, etching machine, cutting machine, etc. We have served more than 20 countries, including Peru, Indonesia, Chile, Pakistan, Turkey, etc.Your inquiry is very welcome.
Our Vision
To provide an excellent product with prompt and accurate service at the highest quality, and at a fair price.
Our Mission
Provide good quality and good design, use advance manufacturing system,
strictly control the material and make process to satisfy various needs of our customer
FAQ
Q1: How can you control your quality?
A1: For each production processing, JUCOS have complete QC system for the chemical composition and Physical properties. After production, all the goods will be tested, and the quality certificate will be shipped along with goods.
Q3: What's the term of payment?
A3: 30% T/T as down payment; 70% T/T before delivery time.
Q4: Can you provide technical support?
A4: We have professional technical staff to provide technical support.
Q5: Why choose us?
A5: We can not only provide you high quality products with competitive price, but also we can supply good technique service which can help you solve problems.
